Round Stop Tail Lamp 12V Black Chrome Clear Lens
Round Stop Tail Lamp 12V Black Chrome Clear Lens
$49.00
Round 12V stop tail lamp for trailer rear lighting with black chrome finish, clear lens, recessed mount, 130mm body and ADR approved stop and tail output.
Part number 102RBC.
Description
Overview
12V stop tail lamp restores rear stop and tail lighting on trailers that run a round recessed lamp. The black chrome finish and clear inactive lens suit builds that need a low profile lamp face while still delivering a red active stop and tail output.
Features
- 130mm round lamp body with a 12mm low profile recessed design.
- 21 LED layout with clear inactive lens and red active stop and tail function.
- 36cm cable with spade terminals for trailer lighting connections.
- ADR approved stop and tail function with IP67 protection.
Specifications and Materials
This lamp measures 130mm round x 12mm, fits a 104mm round cutout and uses a polycarbonate lens. It runs on 12V only and carries stop/tail current draw of 0.31A and 0.04A at 13.8V. Part number: 102RBC.
See the manufacturer technical page
Compatibility and Fitment
Match the cutout size, voltage, mounting style and lamp function before ordering. This 12V stop tail lamp suits trailer rear lighting positions where a recessed round lamp, clear inactive lens and black chrome finish need to line up with the existing panel and wiring. Also check the cable route behind the panel, because this lamp runs the wires out the back of the housing.
Related Parts
Check the related service parts below against the trailer setup before ordering.
| Use | Part number | Part type |
|---|---|---|
| Used with | 102B3C | triple surface mount base |
| Gasket to suit | 102BG | black foam gasket |
| Gasket to suit | 102WG | white foam gasket |
Compliance and Safety
Inspect the mounting face, gasket contact and cable exit before fitting the lamp. Then confirm both stop and tail functions after wiring, because poor earths, loose terminals or pinched cable can cause weak or intermittent rear lighting.
Trailer Applications
Workshops fit this 12V stop tail lamp on trailers that need a compact round rear lamp for stop and tail service. It suits repair work, lamp upgrades and panel replacements where the trailer already carries a 104mm cutout or the body is being prepared for a recessed round light.
Why Choose ICS Trailers
ICS Trailers can help match this lamp with the mounting base or gasket that suits the trailer finish and the way the rear panel is built.
