Description

Overview

Jumbo LED stop rear position module updates existing Jumbo or Designline rear lamp assemblies with LED stop, tail and red retro reflector functions. This module suits trailer rear lighting repairs where the existing lamp body uses the matching HELLA Jumbo recess mount format. Because it runs on 9-33V multivolt power, it suits both 12V and 24V vehicle electrical systems.

Features

• LED stop and rear position module with red retro reflector
• Enhanced Definition Technology for the stop signal function
• 9-33V multivolt operation for mixed trailer fleets
• Pre-wired with 200mm of cable for installation

Specifications and Materials

This Jumbo LED stop rear position module uses a four point recess mount and suits horizontal or vertical mounting. It measures 194mm × 124mm × 34mm, has a 33cm² reflector area, draws 6W on stop and 1W on rear position, and includes reverse polarity protection with a 5000 watt transient voltage suppressor. Part number: 2317BL.

Use the manufacturer Jumbo and Designline LED catalogue for module identification

Compatibility and Fitment

Match the recess mount body, stop and rear position function, reflector requirement and existing lamp housing before ordering. This module updates existing Jumbo or Designline lamps, but it must match the rear lamp assembly already fitted to the trailer. These cross-references show where this part replaces the part numbers and applications listed. Some installations may need minor changes. 2TA 959 030-102, 2TA959030102

Related Parts

Check the related service parts below against the trailer setup before ordering.

Compliance and Safety

This module carries ADR 47/00 and ADR 49/00 compliance for supported stop and rear position lamp applications. Inspect the surrounding lamp body, wiring and sealing surfaces before fitting it. If the existing connector, housing or cable route has corrosion or damage, repair those faults before returning the trailer to service.

Trailer Applications

Trailer workshops fit this module during rear lamp repairs, LED upgrades and stop or tail lamp fault work. Fleets also use the Jumbo LED stop rear position module when replacing older globe type modules while keeping the existing Jumbo or Designline rear lamp body.

Cross-reference and Suitability

This part cross-references to or suits the following equivalent part numbers and compatible alternatives:
