Air Brake Push-In Swivel Male Elbow 3/8in x 1/4 NPT
Air Brake Push-In Swivel Male Elbow 3/8in x 1/4 NPT
$14.00
This brass 90° push-in air brake elbow connects 3/8in nylon tube to a 1/4 NPTF female port, while the male swivel body supports line orientation in confined pneumatic installations and carries a 150 psi rating.
Part number 88-005S-0604.
Description
Overview
This swivel male elbow turns a 3/8in nylon air line through 90° into a 1/4in NPTF female port. The push-in tube end speeds installation, while the threaded swivel body lets the elbow face the required direction without forcing a tight tube bend.
Features
- Connects 3/8in outside-diameter tube to a 1/4-18 NPTF male thread.
- 90° form suits compact routing beside valves and tanks.
- Brass body with a reusable push-to-connect collet for tube removal.
- Rated to 150 psi across a -40°C to 93°C operating range.
Specifications and Materials
The fitting has 1.08in and 1.14in centre-to-end dimensions, a 9/16in hex and a 1.44in overall length. Part number: 88-005S-0604.
See the manufacturer product specifications
Compatibility and Fitment
Match the tube by outside diameter, not bore, and confirm a 1/4in NPTF female port. Choose this swivel male elbow only for 3/8in imperial tube; do not substitute 8mm or 10mm tube or BSP threads.
These cross-references show where this part replaces the part numbers and applications listed. Some installations may need minor changes. DQ69DOTS0604, 35-S690604, 35S690604, AQ69-DOTS-6X4, AQ69DOTS6X4, 1869X6S, 1869X6X4S, 3109 56 14DOT, 31095614DOT
Related Parts
Check the related service parts below against the trailer setup before ordering.
| Use | Part number | Part type |
|---|---|---|
| Fixed alternative | 88-005-0604 | 90° push-in male elbow |
| Alternate angle | 88-005DS-0604 | 45° swivel elbow |
| Related version | 88-005S-0602 | 3/8in tube x 1/8 NPT |
| Related version | 88-005S-0606 | 3/8in tube x 3/8 NPT |
| Related version | 88-005S-0608 | 3/8in tube x 1/2 NPT |
Compliance and Safety
Cut the tube square, remove burrs and push it fully into the collet so the seal engages. Then pressurise and leak-test both connections; depressurise the circuit before releasing the tube or disturbing the joint.
Trailer Applications
Workshops fit this elbow in air brake, air suspension and auxiliary pneumatic circuits where a straight connector would create a sharp tube bend or poor access. The swivel form helps route the line around nearby brackets, valves and chassis hardware during assembly.
Cross-reference and Suitability
This part cross-references to or suits the following equivalent part numbers and compatible alternatives:
| DQ69DOTS0604 | 35-S690604 | 35S690604 |
| AQ69-DOTS-6X4 | AQ69DOTS6X4 | 1869X6S |
| 1869X6X4S | 3109 56 14DOT | 31095614DOT |
Why Choose ICS Trailers
ICS Trailers supplies air line, fittings and pneumatic repair parts for truck and trailer workshops. If the old fitting cannot be identified, send the tube outside diameter, port thread measurement and a clear photo so the connection can be narrowed down before ordering.
Browse more Air Fittings
Online prices apply to website orders only. In-store pricing may differ.
