Description

Overview

The BPW M16 x 12mm nylon tube fitting connects 12mm outside diameter nylon air line to a compatible M16 threaded port in trailer pneumatic plumbing. Its straight configuration keeps the tube path aligned with the port, which suits installations where an elbow would add an unnecessary turn or consume extra clearance. Because smaller fittings can look similar in photographs, measure the tube outside diameter rather than judging the connection by appearance alone.

Features

• M16 male threaded connection for a compatible metric port.
• 12mm tube connection for nylon pneumatic line.
• Straight layout supports direct in-line tube routing.
• Spanner flats allow controlled installation and removal.

Specifications and Materials

Product type: straight thread-to-tube pneumatic fitting. Thread connection: M16 male. Tube connection: 12mm outside diameter nylon tube. Configuration: straight. Part number: 02.4313.56.00.

Refer to the BPW operator’s manual

Compatibility and Fitment

Before ordering, compare the existing thread diameter, thread pitch, port seat and tube size. The BPW M16 x 12mm nylon tube fitting does not suit smaller 8mm or 10mm tube, while an M16 diameter alone does not confirm the pitch or sealing arrangement. Cut the nylon tube square, remove burrs and keep the end free from scoring so the connection can seal correctly. Also confirm enough clearance for a spanner and a suitable bend radius without loading the fitting sideways.

Compliance and Safety

Depressurise the pneumatic system before loosening the old connection. Inspect the mating port for damaged threads, corrosion or debris, and replace tube that has become flattened, cracked or deeply marked near the connection. Tighten the fitting with suitable tools and avoid forcing mismatched threads. After installation, restore pressure gradually and check the joint for leakage, movement and secure tube retention using an approved workshop method.

Trailer Applications

Workshops use this size in BPW trailer pneumatic circuits where 12mm nylon line runs directly into an M16 port. Typical service work includes compatible air suspension plumbing, pneumatic control lines and replacement of a damaged straight connection. The in-line form suits direct tube runs where the surrounding layout does not require an elbow or tee.

Why Choose ICS Trailers

ICS Trailers supplies straight fittings, elbows, unions, tube connectors and associated pneumatic hardware for trailer repairs. If the old fitting is difficult to identify, send clear photos together with the measured tube outside diameter, thread details and installation location so the team can help narrow down the match.

Browse more Air Fittings
