Description

Overview

The Malco Webb 3 spoke rim clip is a wide clamp for compatible 15-inch three-spoke wheel assemblies. Identification dimensions are 27mm A, 194mm B, 45mm C, 20mm D and 114mm E.

Features

• 194mm three-spoke clamp profile
• 20mm stud opening with 114mm hole centres
• 27mm reach and 45mm body length

Specifications and Materials

A: 27mm. B: 194mm. C: 45mm. D: 20mm. E: 114mm.

Part number: AP6048.

See the BWP spoke wheel clamp technical catalogue for clamp dimensions and fitting guidance.

Compatibility and Fitment

Match the clamp profile, stud opening and hole centres against the removed part before fitting. Webb 3314 applications use 15-inch three-spoke wheels with 3/4-inch studs.

The following cross-reference numbers identify verified equivalent or replacement parts for this exact application. Confirm the selection-critical fitment details against the part being replaced before fitting.

FPTF70, 05.6915.0, IT6048, T04-6048, 3314, FQ6063, TF70

Compliance and Safety

Clean the mounting surfaces, seat the clamp correctly and tighten the wheel nuts evenly to the applicable wheel-end procedure.

Trailer Applications

For compatible 15-inch three-spoke trailer wheels matching the 194mm width, 20mm stud opening and 114mm hole centres.

Cross-reference and Suitability

This part cross-references to the following verified equivalent or replacement part numbers:

Why Choose ICS Trailers

Three-spoke rim clamps can look similar while differing in reach, width and hole centres. ICS Trailers can compare the removed clamp against the 27mm, 194mm, 45mm, 20mm and 114mm measurements before you order. If the old casting number is visible, send the marking or a clear photo so the wheel arrangement can be checked before fitting.

• Useful for matching 15-inch three-spoke wheel assemblies.
• Dimensional checks help separate this clamp from shorter spoke-wheel clips.
