Description

Overview

LED work light delivers wide flood lighting for trailers, service vehicles, machinery, utes and external work areas. The round 200 Series body gives installers a compact lamp for night work, reversing assistance, loading areas and general equipment lighting. Because it uses a 60 degree flood beam, it spreads light across the work zone rather than throwing a narrow driving beam.

Features

• 27W output with 1900lm illumination for strong external work lighting.
• 9-30V Varivolt electronics suit common 12V and 24V vehicle systems.
• 60 degree flood beam gives broad area coverage around trailers and machinery.
• Aluminium housing, polycarbonate lens and IP67 sealing suit exposed installations.

Specifications and Materials

This LED work light uses an anodised aluminium housing, high-impact polycarbonate lens and adjustable stainless steel bracket. The lamp measures 117mm x 117mm x 68mm, so it suits compact external mounting positions where a larger flood lamp would take up too much room.

Part number: LWL226F.

See the Whitevision technical information

Compatibility and Fitment

Check the mounting surface, bracket clearance, wiring route and system voltage before ordering. This LED work light suits 9-30V DC systems, so confirm the vehicle or trailer circuit sits within that range. Also allow enough adjustment room to aim the beam across the work area without blocking doors, ramps, guards or body hardware.

Compliance and Safety

Mount the lamp securely and protect the wiring from sharp edges, vibration, heat and moving components. After installation, test polarity, beam aim, bracket tension, cable protection and switching before returning the vehicle or trailer to service.

Trailer Applications

Workshops fit this style of round flood lamp to enclosed trailers, service bodies, machinery trailers, utes, plant equipment and yard vehicles. The broad beam helps light loading zones, coupling areas, side workspaces and equipment surrounds where direct task lighting matters.

Why Choose ICS Trailers

ICS Trailers can supply work lights alongside cable, plugs, terminals, switches, conduit and other trailer electrical hardware, so the lighting job can be matched with the rest of the repair or fit-out.
