LED Reverse Strip Light 12V 237mm
LED Reverse Strip Light 12V 237mm
$52.00
12V LED reverse strip light for trailer reverse lighting repairs, with 12 LEDs, clear lens, IP67 protection, 40cm cable and a recessed 237mm x 25mm x 3mm low-profile body for tight rear panels.
Part number 235W12E.
Description
Overview
12V LED reverse strip light restores white reverse signalling on trailer, body and rear lighting setups. Its slim recessed body suits rear panels where a low-profile lamp needs to sit cleanly in the mounting surface rather than stand proud on a bracket.
Features
- Reverse lamp function with 12 LEDs behind a clear lens.
- Recessed low-profile body suits tight rear lighting positions.
- 40cm cable supports routing through the rear panel or bodywork.
- IP67 rating helps protect the lamp against dust and water entry.
Specifications and Materials
The 12V LED reverse strip light measures 237mm x 25mm x 3mm and fits a 203mm x 19mm cutout. It draws 0.26A at 13.8V and uses the 235 Series recessed single-function lamp format.
Part number: 235W12E.
See the official 235 Series technical guide
Compatibility and Fitment
Match this lamp to a 12V reverse lighting circuit, clear reverse lamp position and recessed mounting cutout before ordering. Also check the rear panel has enough clearance behind the cutout for the body, grommet and cable route.
Mount the white reverse lamp horizontally, run the wiring through the rear surface, then fix the lamp evenly so the seal sits correctly in the cutout. If the trailer needs surface mounting instead, check the matching 235 Series bracket options.
Related Parts
Check the related service parts below against the trailer setup before ordering.
| Use | Part number | Part type |
|---|---|---|
| Bracket to suit | 235B1B | Black single surface-mount bracket |
| Bracket to suit | 235C1B | Chrome single surface-mount bracket |
| Housing to suit | 235BT-2 | Red twin blister tail lamp housing |
| Housing to suit | 235BTC-2 | Grey twin blister tail lamp housing |
Compliance and Safety
This lamp carries ECE reverse approval and CTA reverse approval for reverse lamp use. Follow ADR 13/00 mounting guidance, then test the reverse circuit, earth connection and lamp operation before returning the trailer to service.
Trailer Applications
Workshops fit this style of 12V LED reverse strip light on trailer rear bars, service bodies, ute trays, equipment trailers and compact rear lighting panels. Because the body is narrow and recessed, it suits jobs where a bulky reverse lamp would interfere with the surrounding panel layout.
Why Choose ICS Trailers
ICS Trailers supplies lighting parts for trailer repairs, body builds and workshop fit-outs. Before replacing a reverse lamp, check voltage, cutout size, lamp function, wiring path and rear panel clearance against the existing setup. See more trailer lighting parts in LED Lights
