Description

Overview

The front wheel rim clip secures compatible spoke-wheel rims on front steer assemblies. Key dimensions are 13mm A, 60mm B, 93mm C and 20mm D.

Features

• 13mm reach for the front wheel clamp profile
• 60mm width and 93mm length
• 20mm hole for matching wheel hardware

Specifications and Materials

A: 13mm. B: 60mm. C: 93mm. D: 20mm.

Part number: AP6066.

See the WorkSafe Queensland rim wheel safety guide for servicing guidance

Compatibility and Fitment

Compare all four dimensions with the removed clamp before fitting, because similar front wheel clips can use different reach or stud-hole dimensions.

The following cross-reference numbers identify verified equivalent or replacement parts for this exact application. Confirm the selection-critical fitment details against the part being replaced before fitting.

FP6059, FQ6059, 05.7122.0, BP6059, FL52-1430, IT6059, WP-722, WT6059

Compliance and Safety

Inspect the clamp, stud, nut, spider and rim mounting faces before assembly. Replace cracked, bent or heavily corroded components before service.

Trailer Applications

This clamp suits compatible front wheel applications including Kenworth, Mack and International vehicles where the existing dimensions match.

Cross-reference and Suitability

This part cross-references to the following verified equivalent or replacement part numbers:

Why Choose ICS Trailers

Front steer rim clips can look similar while using different reach, width or hole dimensions. ICS Trailers can compare the removed clamp, wheel position and old markings before you order, especially when the casting is worn or partly unreadable.

• Check the 13mm reach and 20mm hole before fitting this version.
• Send clear photos and all four measurements when identification is uncertain.
