Description

Overview

22.5×8.25 aluminium wheel suits 10/285 heavy trailer and truck wheel-end setups where the hub bore, bolt holes, offset and load rating match. The inside-polished finish suits applications where the visible inner face matters, while the aluminium construction keeps weight down compared with many steel wheel options.

Features

• 22.5×8.25 aluminium wheel for 10/285 fitment
• Inside-polished finish for the inner wheel face
• 26mm bolt holes with 220mm hub mounting bore
• 3350kg load capacity with 168mm offset

Specifications and Materials

This 22.5×8.25 aluminium wheel uses a 10-stud 285.75mm pitch circle diameter, 26mm bolt diameter and 220mm hub mounting bore. The wheel has 20mm wall thickness, 168mm offset and 3350kg load capacity. Part number: ALPR285.

It includes a valve stem, so check the existing wheel, stud pattern, bore, offset and axle rating before fitting.

aluminium wheel fitment service guide

Compatibility and Fitment

Match the 10/285 stud pattern, 220mm hub bore, 26mm bolt holes, 168mm offset and load rating before ordering. This 22.5×8.25 aluminium wheel suits matching hub-piloted heavy vehicle and trailer wheel-end applications. These cross-references show where this part replaces the part numbers and applications listed. Some installations may need minor changes. 710.0031, 7100031

Compliance and Safety

Clean the hub mounting face before fitting, then confirm the wheel seats flush against the hub. Also check stud standout, nut engagement, tyre rating and axle load before the trailer returns to service.

Trailer Applications

Workshops fit this 22.5×8.25 aluminium wheel on compatible heavy trailer, truck and fleet wheel-end setups using 10/285 fitment. Use the inside-polished finish where the wheel position and presentation call for a polished inner face.

Cross-reference and Suitability

This part cross-references to or suits the following equivalent part numbers and compatible alternatives:

Why Choose ICS Trailers

ICS Trailers supplies wheel-end parts for trailer repairs, fleet servicing and workshop fitment where size, stud pattern and load rating need to be checked before ordering. Find more trailer wheel-end parts in our Wheels category
