Description

Overview

LED flasher unit controls trailer indicator and hazard warning flash rate on 12V and 24V electrical systems. This 3 pin electronic unit suits LED indicator lamps that need a compatible flasher instead of an electronic pulse module.

Features

• 9-33V DC operating range suits both 12V and 24V systems.
• Maintains 90 +/- 30 flash signals per minute for direction indication and hazard warning.
• Handles lamp loads from 1W to 42W.
• 3 pin electronic layout suits universal LED indicator lamp connection.

Specifications and Materials

This LED flasher unit carries a 42W maximum load and supports LED indicator circuits across a wide DC voltage range. Protection rating changes with mounting position, so fit the terminals downward for IP54 surface mounting or use IP53 guidance for pendant and side surface mounting.

Part number: 3040.

See the HELLA indicator flasher unit technical data for compatible flasher unit specifications

Compatibility and Fitment

Check the vehicle voltage, pin layout, lamp load and mounting position before ordering. Also confirm the indicator lamps do not already use a built-in electronic pulse setup, because this LED flasher unit suits universal LED indicator lamp circuits without that feature.

These cross-references show where this part replaces the part numbers and applications listed. Some installations may need minor changes. 4JZ 177 846-007, 4JZ177846007

Related Parts

Check the related service parts below against the trailer setup before ordering.

Compliance and Safety

Confirm flash rate after installation, then test both direction indicators and hazard warning operation. If the trailer circuit has mixed LED and bulb loads, check the total wattage and connection quality before returning the trailer to service.

Trailer Applications

Workshops fit this LED flasher unit during LED indicator conversions, trailer lighting repairs and mixed 12V or 24V electrical work. It suits service jobs where the flash rate must remain stable after replacing conventional indicator lamps with LED lamps.

Cross-reference and Suitability

This part cross-references to or suits the following equivalent part numbers and compatible alternatives:
