BPW ECO Plus 10/12T Dust Seal

Allan Davis on 10/08/2026

BPW ECO Plus 10/12T dust seal for trailer hub
BPW ECO Plus 10/12T Dust Seal - Image 2

BPW ECO Plus 10/12T Dust Seal

$12.00

BPW ECO Plus 10/12T dust seal for the item 432 wheel-end position, with a 67mm bore, 93mm main outer profile and 90.5mm overall length. Match the hub generation and stepped seal profile before replacement.

Part number AP4184G.

Quick Quote

SKU: AP4184G Category: Tags: , , , , , , , , , , , , , , , , Brand:
This field is for validation purposes and should be left unchanged.

Description

Overview

BPW ECO Plus 10/12T dust seal protects the outer wheel-end sealing area on matching ECO Plus hub assemblies. Its long stepped sleeve profile differs from the flatter dust seal used elsewhere in the hub, so the 67mm bore and 90.5mm overall length are important identification points.

Features

  • Item 432 position in the ECO Plus 10–12 tonne hub assembly.
  • 67mm internal diameter with a 93mm main outer profile.
  • 90.5mm overall length.
  • Plastic construction for the hub sealing position.

Specifications and Materials

Product type: wheel hub dust seal. Dimensions: 67mm ID x 93mm main OD x 90.5mm long.

Part number: AP4184G.

See the BPW wheel-end technical information

Compatibility and Fitment

Match the 10–12 tonne ECO Plus hub generation and the seal profile before ordering, because the smaller ECO Plus version uses a different item 432 seal. These cross-references show where this part replaces the part numbers and applications listed. Some installations may need minor changes. 03.120.45.16.0, 0312045160, 015.108, 015108

Related Parts

Check the related service parts below against the trailer setup before ordering.

Use Part number Part type
Used with AP4183G Seal carrier
Used with AP4235G Hub seal
Used with AP0650T Inner bearing 33118
Used with AP0633T Outer bearing 33213



Compliance and Safety

Inspect the sleeve seating surfaces for wear or damage, then fit the replacement squarely so the stepped profile is not distorted during hub assembly.

Trailer Applications

Workshops replace the BPW ECO Plus 10/12T dust seal during bearing, hub-seal and wheel-end repairs on compatible 10–12 tonne ECO Plus trailer axles.

Cross-reference and Suitability

This part cross-references to or suits the following equivalent part numbers and compatible alternatives:

03.120.45.16.0 0312045160 015.108
015108



Why Choose ICS Trailers

This seal is easy to confuse with another ECO Plus dust seal because both occupy similar wheel-end service positions. Send the old seal dimensions, axle details or a clear hub photo if you need help separating the 10–12 tonne stepped sleeve from the smaller version.

  • Compare the seal carrier and bearing arrangement while the hub is dismantled.
  • Use the 67mm bore and 90.5mm length as practical identification checks.
