Air Brake Push-In Swivel Male Elbow 5/8in x 1/2 NPT
Air Brake Push-In Swivel Male Elbow 5/8in x 1/2 NPT
$29.00
This brass 90° push-in elbow connects 5/8in nylon air brake tube to a 1/2in NPTF female port, with a swivel base for accurate line alignment, reusable release collet and pre-applied thread sealant.
Part number 88-005S-1008.
Description
Overview
This swivel male elbow connects 5/8in SAE J844 air brake tube to a 1/2in NPTF female port through 90°. Rotate the outlet after tightening so the larger tube follows its planned path without loading the collet.
Features
- Push-to-connect collet accepts 5/8in OD nylon tube.
- 1/2-14 NPTF male thread carries pre-applied sealant.
- Brass body swivels at its base.
- Working pressure reaches 150 psi from -40°C to 93°C.
Specifications and Materials
Overall length is 2.18in and the thread hex is 7/8in. A reusable release collet retains the tube against its internal seal. Part number: 88-005S-1008.
Compare dimensions and ratings in the manufacturer fitting specifications before ordering.
Compatibility and Fitment
Measure tube OD, not bore; it must be 5/8in. Confirm a 1/2in NPTF port rather than BSP. Use this swivel male elbow only when both match, as 16mm tube is not equivalent.
These cross-references show where this part replaces the part numbers and applications listed. Some installations may need minor changes. DQ69DOTS1008, 35-S691008, 35S691008, 1869X10S, 269PPSDOT-10D, 269PPSDOT10D, BP269PPSDOT-10D, BP269PPSDOT10D, 691008S, 02569-1008, 025691008, 121030.67, 12103067, 1579-10-8, 1579108, 169PMT-10-8, 169PMT108, 269PCS-10×8, 269PCS10x8, 269PPSDOT-10D-Y, 269PPSDOT10DY, 91238, 95411431M, 969-10PXDOTS, 96910PXDOTS, 969-1-108, 9691108, AQ69-DOTS-10X8, AQ69DOTS10X8, D7069DTS10D, D7069DTS-10D, DQ69DOTS-10X8, DQ69DOTS10X8, DQ69S-108, DQ69S108, NP69SW-10-8, NP69SW108, PC1469SW10D, PC1469SW-10D, PL136910D, PL-1369-10D, PP69SH-DOT, PP69SHDOT
Related Parts
Check the related service parts below against the trailer setup before ordering.
| Use | Part number | Part type |
|---|---|---|
| Alternate style | 88-005-1008 | Fixed 90° elbow, same fit |
| Alternate angle | 88-005DS-1008 | 45° swivel elbow, same fit |
| Alternate thread | 88-005S-1006 | 3/8in NPTF version |
| Alternate thread | 88-005S-1012 | 3/4in NPTF version |
Compliance and Safety
Cut the tube square and remove burrs. Push it to the stop, then pull back to confirm engagement. Because 5/8in tube is stiff, set the outlet angle before clamping the line. Depressurise first and leak-test both joints after assembly.
Trailer Applications
This size suits brake supply, suspension and auxiliary circuits where 5/8in tube meets a 1/2in port. The elbow routes the line around reservoirs, relay valves, crossmembers and mounting plates.
Cross-reference and Suitability
This part cross-references to or suits the following equivalent part numbers and compatible alternatives:
| DQ69DOTS1008 | 35-S691008 | 35S691008 |
| 1869X10S | 269PPSDOT-10D | 269PPSDOT10D |
| BP269PPSDOT-10D | BP269PPSDOT10D | 691008S |
| 02569-1008 | 025691008 | 121030.67 |
| 12103067 | 1579-10-8 | 1579108 |
| 169PMT-10-8 | 169PMT108 | 269PCS-10×8 |
| 269PCS10x8 | 269PPSDOT-10D-Y | 269PPSDOT10DY |
| 91238 | 95411431M | 969-10PXDOTS |
| 96910PXDOTS | 969-1-108 | 9691108 |
| AQ69-DOTS-10X8 | AQ69DOTS10X8 | D7069DTS10D |
| D7069DTS-10D | DQ69DOTS-10X8 | DQ69DOTS10X8 |
| DQ69S-108 | DQ69S108 | NP69SW-10-8 |
| NP69SW108 | PC1469SW10D | PC1469SW-10D |
| PL136910D | PL-1369-10D | PP69SH-DOT |
| PP69SHDOT |
Why Choose ICS Trailers
Because 5/8in tube resembles 16mm line, measure it before ordering. Also check the thread form and send a connection photo if the port cannot be identified.
