Description

Overview

Straight torque / radius rod bush 25mm ID cushions movement through the hanger end and helps keep the suspension link located under load. It suits Reyco hanger-end service where worn rubber starts adding slack, noise or uneven movement through the rod connection.

Features

• 47mm / 80mm stepped OD for housing match-up
• 25mm ID for pin and sleeve fitment checks
• 72mm length for bush width matching at the hanger end
• Rubber construction for controlled movement in torque and radius rod joints

Specifications and Materials

This straight hanger-end bush measures 47mm / 80mm on the outside diameter, 25mm on the inside diameter and 72mm in length, so buyers can match the housing, pin and bush width before ordering. It suits torque and radius rod hanger-end service on Reyco suspension setups and should be checked with the surrounding sleeve, pin and washers during repair work. Part number: SP1314.

Read the Reyco 102/102W/102CC maintenance manual

Compatibility and Fitment

Match both outside diameters, the inside diameter and the overall length before ordering, then inspect the hanger eye and pin or sleeve while the joint is apart. Also check the housing for oval wear, because a fresh bush will not correct a damaged eye. These cross-references show where this part replaces the part numbers and applications listed. Some installations may need minor changes. 09.1310.0, 0913100, FL83.2160, FL832160, IT1310N, WT1310, Reyco T-1842, ReycoT1842, TRB6003

Compliance and Safety

Clean the housing bore before pressing the bush in, then confirm the pin or sleeve passes through square without cutting or twisting the rubber. Replace bushes that show splitting, crush damage or loose fit in the housing, because joint movement can affect suspension alignment and tyre wear.

Trailer Applications

Workshops fit this straight torque / radius rod bush 25mm ID during hanger-end rebuilds, torque rod service and routine bush replacement on Reyco mechanical suspension setups. It also suits jobs where the original bush has hardened, shifted or worn through after repeated load cycles.

Cross-reference and Suitability

This part cross-references to or suits the following equivalent part numbers and compatible alternatives:
