Description

Overview

York Duratrac air spring assembly helps keep trailer ride height consistent, even when loads change across the day. It supports stable axle alignment and reduces shock transfer into the chassis when an old unit starts leaking or sagging. A fresh air spring can also improve suspension response so the trailer tracks more predictably on rough Victorian roads.

Features

• Complete air spring assembly for York Duratrac trailer suspension
• Rated for up to 7 bar (100psi) operating pressure
• Works across a wide temperature range from -40°C to +70°C
• Designed to restore load support and ride control

Specifications and Materials

This York Duratrac air spring assembly is supplied as a complete replacement air spring suitable for heavy vehicle trailer suspension service.

• Operating pressure: max. 7 bar (100psi)
• Operating temperature range: -40°C to +70°C
• Application: York Duratrac trailer suspension
• Type: air spring assembly

Part number: SP0083A.

See the air suspension overview explaining air springs for technical reference

Compatibility and Fitment

This cross-reference listing means this part is a suitable replacement for the part numbers and applications shown. Some changes in installation may be required. P10.9141.CP, P109141CP, P109141, 1110.5-17, 1110517, W01-358-9141, W013589141, W01-358-9121, W013589121, 1T19L7, 1R14-215, 1R14215, 1R13-047, 1R13047, 566-26-3-051, 566263051, 61610443, 61610443GYR, 90557110, 3529141

Compliance and Safety

Support the trailer safely and depressurise the system before removal. Inspect the air lines and height control components because leaks elsewhere can shorten service life. Keep within the stated 7 bar limit and avoid heat sources outside the -40°C to +70°C range. Follow the suspension maker’s installation guidance so mount hardware and alignment remain correct.

Trailer Applications

This York Duratrac air spring assembly suits trailer suspension setups that rely on air springs for ride height control and load support. It also suits general on-road freight trailers where consistent ride height helps tyre wear and braking stability. Replacing a worn unit can improve handling feel and reduce bottoming on uneven surfaces.

Cross-reference and Suitability

This part cross-references to or suits the following equivalent part numbers and compatible alternatives:

Otherwise, match the old bellows and piston layout before ordering when multiple air spring styles exist in the same suspension family.
