Description

Overview

Hendrickson INTRAAX air spring assembly 14in to 17in supports Hendrickson trailer suspension setups where the air spring sets ride height and absorbs road shock. It helps keep the trailer stable and reduces harshness through the suspension.

Features

Hendrickson INTRAAX air spring assembly 14in to 17in suits INTRAAX trailer suspensions specified for a 14in to 17in ride height range. If an air bag leaks, cracks, or loses height, this complete assembly provides a direct replacement option.

• Rated operating pressure up to 7 bar (100psi)
• Operating temperature range -40°C to +70°C
• Designed for trailer suspension duty
• Built as a complete air spring assembly

Specifications and Materials

Part number: SP0070GA.
This Hendrickson INTRAAX air spring assembly 14in to 17in is specified for Hendrickson INTRAAX applications and the listed ride height range, so confirm your suspension model and ride height before ordering.
Use the Hendrickson trailer common parts literature page to confirm INTRAAX air spring identifiers before ordering

• Suitability: Hendrickson INTRAAX trailer suspension
• Ride height coverage: 14in to 17in
• Max operating pressure: 7 bar (100psi)
• Operating temperature: -40°C to +70°C

Compatibility and Fitment

This cross-reference listing means this part is a suitable replacement for the part numbers and applications shown. Some changes in installation may be required. S-23612, S23612, C-23612, C23612, W01-358-9645, W013589645, 1T19MB7W12, 1T15MBTW12, 9 10BP-22 P 739, 910BP22P739

Compliance and Safety

Support the trailer safely before you depressurise the air suspension. Isolate air supply lines, then check for leaks after installation. Also inspect height control valve linkages and torque fasteners to the suspension maker’s specifications because incorrect ride height can accelerate tyre and bush wear.

Trailer Applications

Hendrickson INTRAAX air spring assembly 14in to 17in commonly fits INTRAAX trailer suspensions used on semitrailers, skel trailers, and general freight trailers. It suits applications where the air spring provides the primary springing medium rather than steel springs. When you need to restore ride height and reduce sway under load, it is a sensible service replacement.

Cross-reference and Suitability

This part cross-references to or suits the following equivalent part numbers and compatible alternatives:
