SAF Mark V Landing Leg Set 14″ Komp Foot

Allan Davis on 05/06/2026

SAF Mark V landing leg set 14 inch Komp Foot

SAF Mark V Landing Leg Set 14″ Komp Foot

$2,045.00

Landing leg set for SAF Mark V trailer support applications, with square body legs, Komp Foot bases, 14″ travel, high and low gear ratios, Black Armour metal treatment and matched set format for commercial trailer service and fleet replacement work.

Part number LL3502S.

Available on back-order

Request Freight Quote

Quick Quote

1. My driveway is sealed with an even surface
2. There is reasonable vehicle access with height clearance.
3. I acknowledge the delivery is to the front door, carport, or closest practical delivery point as deemed by the driver.

SKU: LL3502S Category: Tags: , , , , , , , , , , , , , , , , , Brand:
This field is for validation purposes and should be left unchanged.

Description

Overview

SAF Mark V landing leg set supports trailer coupling, uncoupling and parked trailer stability in heavy commercial trailer applications. This square body Mark V set uses Komp Foot support with 14″ travel, so it suits replacement work where the trailer needs a shorter travel landing leg set with high load capacity.

Features

  • 14″ travel Mark V landing leg set with Komp Foot support.
  • Square body construction suits heavy trailer landing gear applications.
  • Double-D crank handle connection gives a stronger crank connection.
  • Black Armour metal treatment helps protect against moisture, stone chipping and salt.

Specifications and Materials

Part number: LL3502S.

This SAF Mark V landing leg set carries a lift capacity of 28,350kg, static load rating of 90,720kg and side-load capacity of 14,515kg. Gear ratios are 33.8 in low gear and 2.5 in high gear.

The set uses an 80,000psi minimum yield upper housing and retract tube, heat-treated ductile iron spur gears, a rolled 1-5/8″ double lead elevating screw and an industry-standard TTMA mounting plate.

The 14″ compensating foot set format uses geared and slave legs with a 1 metre cross shaft and crank handle option.

The manufacturer Mark V landing gear information gives capacity, cranking and series details

Compatibility and Fitment

Match the trailer mounting pattern, travel requirement, foot style and crank handle connection before ordering. Also check trailer ground clearance and fifth wheel lift requirement, because landing gear with the wrong travel range can over-extend or leave the trailer sitting too low.

Related Parts

Check the related service parts below against the trailer setup before ordering.

Use Part number Part type
Replacement handle LL3301 Crank handle
Speed crank option LL3303 Short speed crank handle
Related version LL3564 19″ Komp Foot landing leg set
Related version LL3502 19″ skid foot landing leg set
Related version LL3501 19″ wheel foot landing leg set



Compliance and Safety

Inspect the landing gear before use and replace damaged, cracked or bent components before loading the trailer. When fitting, confirm both legs sit square, the bracing supports the frame correctly and the crank operates freely through both gear ranges.

Trailer Applications

Workshops fit this SAF Mark V landing leg set to semi-trailers that need a square body Mark V landing gear set with Komp Foot support. It suits fleet repair, trailer rebuild and complete landing gear replacement where the 14″ travel format matches the original setup.

Why Choose ICS Trailers

ICS Trailers helps match landing legs by travel, foot style, mounting pattern and related handle parts before the trailer returns to work. Browse more trailer support parts in our Landing Legs
