Description

Overview

Stemco hub cap gasket seals the hub cap mounting face on 5-1/2″ 6-hole trailer wheel ends. It suits general purpose trailer axles using a 140mm PCD hub cap gasket with 5/16″ or 8mm bolt holes. Replace the gasket whenever the hub cap comes off, or when the old gasket has crushed, torn or no longer seals cleanly.

Features

• 6-hole hub cap gasket for 5-1/2″ bolt circle applications.
• Matches 140mm PCD hub caps with 5/16″ or 8mm mounting bolts.
• 159mm outside diameter with 123mm inside diameter.
• Single replacement gasket supplied per unit.

Specifications and Materials

Part number: 330-3009.

This Stemco hub cap gasket suits 6-hole hub caps on general purpose trailer axles. Key dimensions include 5-1/2″ or 140mm bolt circle, 5/16″ or 8mm bolt size, 123mm inside diameter and 159mm outside diameter.

Use the official Stemco hub cap parts guide when matching hub cap bolt circle, bolt size and gasket number

Compatibility and Fitment

Match this gasket to the hub cap bolt pattern, bolt size and sealing face before ordering. Also check the hub cap flange for bends or corrosion, because an uneven cap can damage the new gasket and allow oil or grease leakage. These cross-references show where this part replaces the part numbers and applications listed. Some installations may need minor changes. AP4045, 453795, CR453795, 180.10619.1, 180106191, M-2768, M2768, 13-7151, 137151, 13-7151B, 137151B, L-453, L453, 8-304, 8304, 120MF315, 2208-X-430, 2208X430, 401528P, 071-124-00, 07112400, WA14-5048, WA145048, GKT009

Related Parts

Check the related hub caps below against the trailer setup before ordering.

Compliance and Safety

Clean the hub and cap faces before fitting the gasket. Replace damaged cap bolts, and tighten the hub cap evenly so the gasket compresses without pinching. After service, check for lubricant seepage around the cap before the trailer returns to work.

Trailer Applications

Workshops use this Stemco hub cap gasket during trailer hub cap removal, wheel end servicing and hub cap replacement. It suits general purpose trailer axle work where the existing cap uses a 5-1/2″ 6-hole mounting pattern.

Cross-reference and Suitability

This part cross-references to or suits the following equivalent part numbers and compatible alternatives:
