Description

Overview

The BPW lightweight 9000 hub cap closes the external thread on matching conventional grease-filled wheel hubs. This oval metal cap uses an M115 x 2 thread, 95mm across-flats profile, 107mm inside diameter and 61mm depth, distinguishing it from old-generation M115 x 3 and ECO internal-thread caps.

Features

• Zinc-plated metal construction with an oval cap profile.
• External M115 x 2 thread for the lightweight 9000 conventional hub.
• 95mm spanner size for workshop removal and installation.
• 9 tonne wheel-end application.

Specifications and Materials

Application: lightweight 9000 conventional grease hub. Thread: M115 x 2 external. Inside diameter: 107mm. Depth: 61mm. Spanner size: 95mm across flats.

Part number: AP4094G.

For manufacturer support, see BPW original spare parts support

Compatibility and Fitment

Check the removed cap for the oval body, 95mm across-flats size and M115 x 2 external thread before ordering. The main mismatch risk is confusing this cap with the visually similar M115 x 3 old-generation version or an internally threaded ECO cap.

Cross-reference numbers: 0321223090, BP4048, IT3398, T04-4064, WT4048, 070.066.

Related Parts

Check the related service part below against the wheel-end setup before ordering.

Compliance and Safety

Clean the mating threads before fitting and start the cap square by hand. Tighten it to the applicable BPW service specification and inspect the sealing area for damage or contamination.

Trailer Applications

Workshops use the BPW lightweight 9000 hub cap when servicing matching 9 tonne conventional trailer hubs, particularly where the original external-thread grease cap is damaged, corroded or removed during bearing service.

Cross-reference and Suitability

This part cross-references to the following verified equivalent or replacement part numbers:

Why Choose ICS Trailers

Lightweight BPW caps can be mixed up with older or ECO versions because the overall size is similar while the thread arrangement changes. Compare the M115 x 2 external thread, oval body and 95mm across-flats size with the removed cap. ICS Trailers can use old markings, photos and axle details to help narrow down the match.

• Identify the matching O-ring when the seal also needs replacement.
• Compare alternate numbers when the original cap marking is difficult to read.
