Description

Overview

The BPW ECO Plus 3 hub cap closes a grease-filled wheel hub and seals the bearing area with its supplied O-ring. This steel version uses an M135x2 internal thread, 139mm outside diameter and 70mm depth for matching 10 to 12 tonne wheel ends.

Features

• Supplied with the hub-cap O-ring.
• 110mm A/F service profile.
• Steel cap for grease-filled wheel ends.

Specifications and Materials

Thread: M135x2 internal. Outside diameter: 139mm. Depth: 70mm. Spanner size: 110mm A/F. Hub type: grease filled.

Part number: AP4247G.

See BPW Wheel End technical information

Compatibility and Fitment

Match the M135x2 thread and ECO Plus 3 hub generation before fitting. Earlier ECO Plus caps commonly use M136x2.5, so do not select the cap by appearance alone.

Equivalent or replacement part number:

0321229060TS.

Related Parts

Compliance and Safety

Fit a fresh O-ring whenever the cap is removed. Tighten the M135x2 cap to 350 Nm and start it squarely on the hub thread.

Trailer Applications

The BPW ECO Plus 3 hub cap suits matching 10 to 12 tonne trailer wheel ends, including retrofit arrangements using the steel cap and O-ring combination.

Cross-reference and Suitability

Equivalent or replacement part number:

Why Choose ICS Trailers

The main ordering risk is confusing this M135x2 cap with the earlier M136x2.5 ECO Plus version. Compare the old thread, 139mm outside diameter and 70mm depth before ordering. If markings are difficult to read, send hub photos and axle details so ICS Trailers can help narrow down the match.

• Inspect the O-ring seating area while the cap is off.
• Match the 110mm A/F profile with the correct service tool.
