Description

Overview

Wabco Raise/Lower Valve gives the operator direct manual control over raising and lowering trailer air suspension with a hand lever. It suits air suspension systems that need manual height adjustment during loading, docking, or workshop setup, and it also supports controlled suspension changes without relying on electronic inputs.

Features

• Hand-operated suspension control valve for manual raise and lower adjustment
• Four M12x1.5 ports plus one M16x1.5 supply port for common trailer air suspension plumbing
• 10 bar maximum operating pressure with integrated check valve on Port 1
• 122mm handle length, 55mm mounting hole spacing, and maximum actuation torque of 7Nm

Specifications and Materials

The Wabco Raise/Lower Valve uses four M12x1.5 control and delivery ports plus one M16x1.5 supply port. It operates to 10 bar, works from -40°C to +80°C, and uses a hand lever that returns suspension control directly to the operator. Mounting is 4 x M8, and the overall valve size is compact enough for common trailer chassis installations. Part number: SP0230.

For technical layout and port configuration, see the official WABCO technical page online

Compatibility and Fitment

Check the valve style, port thread sizes, mounting pattern, and lever travel before ordering. This cross-reference listing means this valve is a suitable replacement for the part numbers and applications shown. Some changes in air line plumbing may be required. 4630320200, 4630320207, 02.431.12.80.0, 0243112800, WSK22, F001882, 1291360, 1506100, 8143272, 1065259, 8025172000, 4C465A687AA, TDAS4630320200, CF351925F001882, UFA1449001, 3766-010, 3766010, GV66002410, 159118, 500002862, 42089956, 2128001, S4630320200, 945047, 9450471, 5009450471, 500945047, 80251720000, 21151103110, 77414, 774140, 1142217, 4110281, FBU3132, EXABRB614, 502918101, A05030209, A05030208, 6300-4630320200, 63004630320200, 81436196004, 81436196006, 223-653, 223653, 0003275125, 0003290425, 0003290825, 910045-00012, 91004500012, 522509X500, 9206944, 309104, 0309104, 0567810, 49530201000, 495149, CV118432, 5001871034, 5000791019, 4425011900, 2089910, 050506, SO50506, 50506, S050506, 3661, 99100360046, 99100362124, T852-077, T852077, 637213060, 6773736, 1698530, WAB4630320200, 22349016, 350600191, 3506-00191, 1013121

Compliance and Safety

Use clean, dry air lines and confirm correct plumbing to the supply, control, exhaust, and suspension delivery ports before returning the trailer to service. When the valve is installed, check for air leaks, smooth lever movement, and correct suspension response across the full operating range.

Trailer Applications

The Wabco Raise/Lower Valve suits trailers that use hand-operated air suspension control for loading docks, height changes, and workshop ride-height adjustment. It also suits service replacements where the original valve used the same port arrangement, lever operation, and mounting layout.

Cross-reference and Suitability

This part cross-references to or suits the following equivalent part numbers and compatible alternatives:
