Description

Overview

Air Spring Assembly Hendrickson Intraax 14in to 17in supports consistent ride height on Intraax trailer suspensions. When an air spring leaks it can reduce height, increase compressor cycling, and affect handling. Replacing the assembly helps restore stable axle loading and more predictable ride control.

Features

• Suits Hendrickson Intraax suspension in a 14in to 17in ride height range
• Rated to 7 bar (100psi) maximum operating pressure
• Operating temperature range: -40°C to +70°C
• Complete air spring assembly format for service replacement

Specifications and Materials

This air spring assembly is specified for a maximum working pressure of 7 bar (100psi) and an operating temperature range of -40°C to +70°C. Check mounting faces and air lines before refitting because damage elsewhere can imitate a failed air spring.

Part number: SP0084GA.

Refer to the Hendrickson Intraax parts list for official fitment guidance and part identification.

Compatibility and Fitment

This assembly suits Hendrickson Intraax trailer suspension configurations that operate in the 14in to 17in ride height band. It helps restore ride height when an existing unit leaks, cracks, or loses air overnight. If problems remain after replacement, check for kinked air lines, leaking fittings, or a mis-set height control valve. Set ride height to the trailer OEM specification after installation because incorrect height can shorten component life.

This cross-reference listing means this part is a suitable replacement for the part numbers and applications shown. Some changes in installation may be required.
W01-358-9646, W014559646, W013589646, P10.9646.CP, P109646CP, S23611, S-23611, HENDRICKSON S-23611, C-23611, HENDRICKSONS23611C23611, 1T19MB7W10 off bag, 1T19MB7W10offbag, 1T15MBTW10, 7 1/2 inch disc brake drum brake, 71/2inchdiscbrakedrumbrake, 9 inch drum brake ride height, 9inchdrumbrakeRideheight

Compliance and Safety

Support the trailer safely, depressurise the system, and leak test all fittings once you re-pressurise. Maintain correct bump-stop clearance because over-extension can damage an air spring. If brackets or arms show cracking, fix the cause before returning the trailer to service.

Trailer Applications

This air spring assembly suits common Intraax-equipped semitrailers and other heavy trailers using air suspension for ride height control. It is best practice to fit replacements in pairs across the same axle line and check the height control linkage afterwards.

Cross-reference and Suitability

This part cross-references to or suits the following equivalent part numbers and compatible alternatives:
