Description

Overview

Battery master switch 2 pole provides off-on battery isolation for trailer, truck and heavy vehicle electrical systems.

The double-pole design disconnects both the battery and field circuit, so it supports safer service work and helps control battery drain during storage.

Features

• Double-pole, 2-position off-on battery master switch.
• Includes removable key for controlled battery isolation.
• Plated steel case suits heavy vehicle electrical service.
• Chrome-plated die-cast lever gives a clear manual switch action.

Specifications and Materials

This battery master switch 2 pole suits 6V to 36V DC electrical systems.

The switch carries a 1000A intermittent load rating and a 125A continuous load rating on the large studs, with 20A continuous load on the small studs.

Part number: 4642.

The switch mounts through a 19mm diameter opening and suits panels up to 4.75mm thick.

manufacturer battery master switch guide

Compatibility and Fitment

Match this switch to the vehicle voltage, current load, circuit layout and panel thickness before ordering.

Use the double-pole layout where the installation needs both battery and field circuit disconnection through one off-on switch.

These cross-references show where this part replaces the part numbers and applications listed. Some installations may need minor changes. 6EK 905 424-001, 6EK905424001

Related Parts

Check the related service parts below against the trailer setup before ordering.

Compliance and Safety

Disconnect power before installation, then tighten the terminals and check the switch action before returning the vehicle to service.

Also mount the switch where the lever remains accessible, while keeping cable routing clear of heat, abrasion and moving parts.

Trailer Applications

Workshops fit this battery master switch 2 pole to trailers, trucks, buses and service vehicles that need a manual battery isolation point.

It suits electrical service work where a controlled off-on disconnect helps protect circuits during maintenance, storage or fault finding.

Cross-reference and Suitability

This part cross-references to or suits the following equivalent part numbers and compatible alternatives:

Why Choose ICS Trailers

ICS Trailers can help match battery isolation hardware to the circuit load, switch function and mounting position. If the installation needs silver contacts or weatherproofing, compare the related switch versions before ordering.
